In recent years, with the wide application of solar power plants, the choice of coating materials in various corrosive environments and special environments has become the focus of everyone's attention. As a core skeletal system that protects the entire photovoltaic power plant, photovoltaic supports have increasingly higher requirements for their material properties. CHIKO Solar, the world's leading photovoltaic bracket manufacturer, has been focusing on the development and development of brackets for 11 years, focusing on promoting the era of "affordable Internet access" from the aspects of new processes, new products, and new technology fields. In recent years, CHIKO Solar has continued to develop and innovate, continuously providing users with efficient and flexible solutions to reduce the cost of electricity, and using galvanized aluminum-magnesium solar mounting system to replace traditional brackets.
The biggest feature of the galvanized aluminum-magnesium solar mounting system is that on the basis of galvanizing, alloy elements such as Al, Mg, Ni, Cr are added. The zinc-aluminum-magnesium coating consists of a primary zinc phase, a zinc / zinc-magnesium binary eutectic phase, and zinc aluminum The magnesium ternary eutectic phase is composed of a dense barrier that effectively prevents the penetration of corrosion factors. Greatly improve the corrosion resistance.
-
1. Corrosion resistance: The magnesium (Mg) component in the coating is beneficial to promote the formation of a very stable and meticulously detailed protective film-simonkolleite (Zn 5 (OH) 8 Cl 2 · H 2 O), which is generated on the surface of the coating Maintaining a film-like cover layer, thereby exhibiting excellent corrosion resistance. The corrosion resistance of galvanized aluminum magnesium is 5-12 times that of galvanized.
-
2. Self-healing performance: After the processed section of the steel plate, the upper plating layer dissolves and gradually covers the section, promoting the formation of a stable protective film. In the initial process, red rust will occur on the exposed cut surface, but after the protective film forms a film-like covering on the cut surface, it prevents further corrosion. Due to the flow of magnesium element, the coating products containing magnesium and aluminum elements form a dense protective film at the incision site over time to increase corrosion resistance; the galvanized cut surface only generates a non-dense and porous covering. After the test, the iron substrate at the cut portion was not covered.
-
3. Friction resistance: It has a low friction coefficient and stable friction characteristics, which is very beneficial to stamping and can reduce the amount of plating wear, thereby reducing the part of the hairs.
CHIKO Solar designs and manufactures high quality solar mounting systems for pitched roof, flat roof and groundopen areas. Whether for small or large-scale projects, standard models or tailor-made systems, we deliver what your need.
CHIKO Solar is a leading manufacturer in solar industry. We provide design & manufacture & sales & service customers support from our head quarters in Shanghai.
We are working with companies from USA, Mexico, Germany, UK, Brazil, Korea, Thailand, Australia, South Africa,Japan etc to provide best services.
We are proud of the fact that more than 4GW solar project from worldwide used CHIKO mounting systems.
Above news from CHIKO Sales & Marketing department
