Common rooftop solar PV mounting bracket selection

Data:2017-10-13

  • This article will be listed in a large, distributed solar pv power plant, common cement and steel tile rooftop PV bracket selection, does not involve the general population glazed piece bracket, inadequacies, hope to add.

  • Cement flat rooftop solar PV mounting bracket selection
  • The most common cement flat roof, the roof also has a small arcuate portion of the cement (e.g. silos, etc.), most of the cement flat roof with an inclination less than 10 degrees, to facilitate the rain fall
  •
  • flat roof solar pv mounting bracket

  • First, cement counterweight France
  • 1.1 pouring concrete barrier in the cement roof, which is the most common installation methods
  • Benefits: stable
  • Does not destroy the roof waterproofing
  • Disadvantages: requires a lot of manual
  • Consuming, concrete barrier curing curing time required more than a week after the concrete barrier fully cured before mounting bracket requires a lot of pre-mold (cement molding)
  • 1.2 precast concrete counterweight
  • Advantages: relative production of concrete barrier province, scheduled in advance with heavy water as mud

  • Second, steel link
  • It is said Cao, "Battle of Red Cliff" when the link with chains will increase the stability of the ship, the same reason, in the bottom of the column bracket Flanges practice, the use of galvanized steel solar mounting brackets to connect with a number of arrays, 500KW even a megawatt the above is a unit of weight to increase the use of stents array of wind resistance, just do the roof anchorage few concrete barrier, a large bracket fixed array.
  • Advantages: Quick and easy to install, easy to disassemble
  • Disadvantages: cost is too high, stand less than 1 per watt cost

  • Third, chemical anchor bolt
  • For precast slab plant, weighing unit area is large, can be done on the roof 5 cm thick layer of cement, followed by chemical anchor bolt mounting bracket when drilling will not damage the roof waterproof layer, currently only a few items to use, use life to be tested
  • Advantages: no expansion force anchor, simple construction, cost savings
  • Disadvantages: poor heat resistance, high-temperature failure, unweldable

  • Fourth, dedicated power plant to install a dual-component adhesive anchorage
  • At present, the case is too small, the promotion will take time, as do you need, anyway brother is generally not used
  • Advantages:      saving time, saving column
  • Disadvantages: high cost
  •
  • Steel tile roof solar mounting bracket selection
  • Steel tile plant installation is simple, but the domestic steel tile life of 10-15 years, after the installation of photovoltaic power plant maintenance difficulties, risks too, personally believe that domestic steel tile roof power plant is mostly a time bomb
  •
  • Chiko solar tile rooftop solar mounting bracket
  •
  • The most common steel tile in three ways: standing seam type, angle Chi type ladder
  • For standing seam type and angle Chi-type steel tile, multi-use steel tile crest, using special aluminum alloy clamp rail mounting bracket
  • Steel tile life of 10-15 years, bearing in 15-30kg per square brackets such multi-use photovoltaic roof tile installation.
  •
  •
